SPECIFICATIONS

After-sales Service Provided: Engineers available to service machinery overseas

Frequency: 50-60HZ

Level of protection: IP54

Maximum powder output: 420g/min

brand name: Haztek

coating: Powder Coating

core components: PLC,Motor

dimension(l*w*h): 300*90*90CM

key selling points: Long Service Life

machine type: Painting Equipment,Coating Equipment

machinery test report: Provided

place of origin: Guangdong, China

power(w): 50W

substrate: Aluminum

type: Coating Spray Gun

video outgoing-inspection: Provided

voltage: 110V-240V, 110-220VAC

warranty: 1 Year

weight (kg): 34

Products Description

Standard input voltage	110-220VAC
Frequency	50-60 Hz
Standard output voltage (to spray gun)	12V
Standard output current (to spray gun)	1.2 A
Spray gun output voltage (static)	100kV
Spray gun output voltage(static)	100uA
Polarity	Negative electrode
Protection level	IP54
Temperature range	-40°C-85°C
Metal powder capability	yes
Other polyester powder capability	yes
Maximum powder discharge rate	420g/min
Air pressure	5.5-6bar
Maximum air consumption	8.5Nm³/h

FAQ

1)Q: Are you a manufacturer or distributor?
A: Haztek is a professional manufacturer of surface finishing equipment with over 10 years, we have exprienced technical team,
manufacture team, quality control team, sales team, etc.
2)Q: How do I make payment?
A: You can directly placed order on Alibaba Or contact with our sales, pay to our company account by T/T bank, we also accept
paypal and western union.
3)Q: How do you ship for me?
A: For small parts or machines, we send you by express, such as DHL, Fedex, door to door delivery. For large orders or big
equipment, we ship you by sea by container.
4)Q: What is the delivery time?
A: For powder coating parts or powder coating machines, normally 1-3 working days. For standard powder coating booths and ovens,
normally 7-15 working days For custom powder coating systems or lines, normally 20-40 working days
5)Q: What about the warranty time?
A: One year for main parts (not including the wearing parts.)
